automatic 3 side sealing stand up pouch making machine

FOB Reference Price:Get Latest Price
US $10,000-30,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Machine Type:
Bag Forming Machine
Bag Type:
bags for food,washing power and sweets,etc
Material:
Plastic
Computerized:
Yes
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
RUIHAO
Model Number:
HDL-500/600
Voltage:
220V
Power(W):
35kw
Dimension(L*W*H):
L11505*W2400*H1865mm
Weight:
6000KGS
Certification:
CE
Feature:
3 side sealing
Automatic:
computerlized
machine type:
automatic 3 side sealing stand up pouch making machine
origin:
made in china
color:
depend on customer requirement
bag types:
bags for food,washing power and sweets,etc
Bag Width (Max):
600mm
Bag length:
500mm
Speed:
30-150 pcs/min
Servo motor:
Yaskawa Japan
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 Year
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
by simple packging
Port
Ningbo
Lead Time :
30 days

automatic 3 side sealing stand up pouch making machine



Use characteristic:

The machine is a kind of modified Model WSD-600A Full-automatic High-speed Three-side sealing bag-making machine and suitable forproducing two-layer or multi-layer three-side sealing laminated film bags (bags for food,washing power and sweets,etc)which take BOPP, PET, CPP, PE, nylon,  aluminum foil and paper as base material. With such characteristics as easy operation,smooth product,stiff and smooth and beautiful appearance,high-strength thermal edge sealing and high bag making speed,it is a kind of ideal equipment for packing and making bags.

 Performance and characteristic:

1s t, The whole machine adoprs industrial control level computer and auxiliary three-servo control. System.

 2ed,All the parameters adopt CRT real time display.The bag-making speed, bag-making length, temperature, counting, punching and conveyor quantity of doubling finished product ,etc.can be preset.

 3th,Releasing tension can be controlled by full-automatic adjustable magnetic powder constant tension control system.

 4th,Automatic deviation-rectifying,double photo electric tracking.

 5th,LPC automatic deviation-rectifying,double photoelectric tracking.

 6th,New type pressure-lifting six time conveying function.

 7th,Computer 16 group PID constant temperature control.

 8th,Pneumatic multi-functional punching, automatic collecting of cut rim charge, electrostatic elimination.

 9th, Technology of double self-standing bag,double concave-convex buckle device is in the lead at home,which can truly make bags by one machine with multiple functions.



Technical parameter:

TypeHDL-600HDL-500

Max.Diam eter of roll material

600mm600mm
Max.width of roll material1240mm1040mm
 bag size width60to600mm60to500mm
 bag size length30to500mm(Ultra long delivers with time)30to500mm(Ultra long delivers with time)
Max. feeding speedapproximately 36m/minApproximately 36m/min
 bag-making capability30-150Section/min30-150Section/min
Temperature controlNormal temperature to 3600CNormal temperature to 3600C
Total power35kw32kw
gas resource0.6mPa(6kg/cm2 )0.6mPa(6kg/cm2 )
Cooling water5L/min5L/min
Machine weight6000kg5500kg
outline diameter L11505*W2400*H1865mmL11505*W2300*H1865mm
