automatic fly knife bottom sealing heavy duty plastic bag making machine

FOB Reference Price:Get Latest Price
US $8,000-15,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Machine Type:
Sealing Machine
Bag Type:
heavy duty bag
Material:
Plastic
Computerized:
Yes
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
RUIHAO
Model Number:
SD 1000-1400
Voltage:
220V
Power(W):
2.2kw
Dimension(L*W*H):
4000* 1700 * 1600 mm
Weight:
1000kg
Certification:
CE
Warranty:
1 year
After-sales Service Provided:
Engineers available to service machinery overseas
machine type:
fly knife bottom sealing heavy duty plastic bag making machine
Speed:
20-100pcs/min
Bag Width (Max):
3000mm
Bag length (Max):
3000mm
Servo motor:
Yaskawa Japan
PLC:
taiwan PLC
inverter:
delta inverter
origin:
made in china
brand:
ruihao
key words:
heavy duty bag making machine
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden packing
Port
Ningbo
Lead Time :
30 days

automatic fly knife bottom sealing heavy duty plastic bag making machine

Futures:
1. steel plate machine frame , starting stable.
2. PLC control, auto counting and set counting alarm
3. it is controlled by inverter.
4. it use heat-sealing & cold-cutting equipment.
5. it is high efficiency, so save time and power.
6. it is a ideal machine to produce non-printing bag , printing bag ,flat bag ,etc.
This type bag making machine is main for plastic heavy bag.    It is special design without control bottom sealing bag making machine, with servo motor to feeding, sealing bag with new type heating wire, which can make heat quickly and save power etc. From film roller to finished bag , it can shaped by one time.

Machine Technical Parameter:

Model

  SD-1000

 SD-1200

  SD-1400

Max bag width

 900mm

 1100mm

  1300 mm

Max bag length

 200-2500mm

 200-2500mm

 200-2500mm

Bag thickness

 0.04-0.25mm

 0.04-0.25mm

 0.04-0.25mm

speed

 20-100pcs

 20-100pcs

 20-100pcs

Main motor

 2.2KW

 2.2KW

 3 KW

Total power

 5KW

 6KW

 7KW

weight

 1000KG

 1300KG

 1500KG

Outline size

 4000 X 1700 X 1600 mm

 4000 X 1900 X 1600 MM

 4000 X 2100 X 1600 MM
